Location:
Khoozestan Province,Abadan city, on the Karoon River
Activity:
Dams and Water Resources
Client:
Khoozestan Water and Power Authority
start date:
Completion Date:
Project Description:
Services:Client consultant in EPC project SWECO Co.
Objectives:
-Flow and tidal affects control and seepage prevention of Persian Gulf brackish water to Karoon River
-Upgrading of required water quality for Agricultural Lands
-Providing required condition for development of seaport,sailing,vessel industry and marine transportation
-Employment,Tourism
-Fishery improvement and development
Project Specification:
Dam Type : concrete diversion dam
Dam length:235 m
Lock Chamber: 25 meter width,160 meter length,10 meter height, equipped with 2 series of sector gates.
Normal Elevation:1.2 m above sea level
Normal spillway: with width of 40 m,capacity of 240 m3/sec and 2 vertical lift gates.
Flood spillway: with width of 120m,capacity of 1080m3/sec and 6 vertical lift gates.
Total volume of Concreting:136,000 m3
Total Volume of Embankment: 1.5 million m3
Status: under construction
